7.16.4. Instance Attributes
Attr
ID
Access
Rule
NV
Name
Data
Type
Description of
Attribute
Value
1
Get
V
Status
DWORD
Interface Status
Default: 2
2
Get
NV
Configuration
Capability
DWORD
Interface capability
flags
Default: 0x000000B5
(DHCP, not stored)
See Instance Attribute 2 -
Configuration Capability
3
Get/Set
NV
Configuration
Control
DWORD
Interface control flags
Default: 2,
if rotary switch = 0
Default: 0,
if rotary switch = 1
4
Get
NV
Physical Link Object
STRUCT
of:
Path to physical link
object
Path size
UINT
Size of Path
Default: 0
Number of 16 bit words in
Path
Path
Padded
EPATH
Logical segments
identifying the
physical link object
Default: ""
The path is restricted to
one logical class segment
and one logical instance
segment. The max. size is
12 bytes.
5
Get/Set
NV
Interface
Configuration
STRUCT
of:
TCP/IP network
interface
configuration
IP Address
UDINT
The device’s IP
address.
Default: None
Value of 0 indicates that
no IP address has been
configured.
Network Mask
UDINT
The device’s network
mask
Default: 255.255.255.0
Value of 0 indicates that
no network mask address
has been configured.
Gateway Address
UDINT
Default gateway
address
Default: 0
Value of 0 indicates that
no gateway address has
been configured.
Name Server
UDINT
Primary name server
Default: 0
Value of 0 indicates that
