Baumer EA Series User Manual

Baumer_EAx_EtherNetIP_EN_MNL 6/81 www.baumer.com
02.20
1. Introduction
1.1. Scope of delivery
Please check the delivery upon completeness prior to commissioning.
Depending on encoder configuration and part number the delivery may include:
 EtherNet/IP encoder
 EDS files and manual (available at www.baumer.com)
1.2. Product classification
Product
Product family
Suitable input in hardware-catalog
EAL580-xxx.xxEN.13160.x
optical - multiturn
EAL580 MT encoder ST13 MT16, optical
EAL580-xxx.xxEN.18130.x
optical - multiturn
EAL580 MT encoder ST18 MT13, optical
EAM580-xxx.xxEN.14160.x
magnetic - multiturn
EAM580 MT encoder ST14 MT16, magnetic
Explanation
- Placeholders marked “x” in the product reference number will not influence the selection
- “MT” means “multiturn”
- “ST” means “singleturn”
- “ST13 MT16” means “13 bits physical singleturn resolution, 16 bits physical multiturn resolution”
EDS file
Several EDS files for different encoder types exist. The EDS files for an EAx580 EtherNet/IP encoder are
available for download at www.baumer.com.
EDS files for the following products are available:
- Baumer EAL 580 ST13MT16
- Baumer EAL 580 ST18MT13
- Baumer EAM 580 ST14MT16
For further information see chapter Import EDS File.
Supported Standards and Protocols
Common Industrial Protocol (CIP™) Vol1, Ed 3.21
EtherNet/IP Adaptation of CIP Vol2, Ed. 1.22, Nov 2016
Encoder Device Profile (Volume 1, 6.21)
ODVA Certification Test CT14 passed with firmware revision 1.002.
Firmware revisions 1.003 and later support Apply_Attributes, Restore and Save services for the Position
Sensor Object to make the configuration of the device more comfortable.
