7.14. Device Level Ring Object (0x47)
The Device Level Ring (DLR) Object provides the configuration and status information interface for the DLR
protocol. The DLR protocol is a layer 2 protocol that enables the use of an Ethernet ring topology. The DLR
Object provides the CIP application-level interface to the protocol.
One instance of the DLR Object is implemented for each pair of DLR ring ports supported.
7.14.1. Class Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
7.14.2. Class Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Description
Semantics of
Values
Value
1
Get
Revision
UINT
Revision of this
object
The current value
assigned to
this attribute is
three (03).
3
7.14.3. Instance Services
Service Code
Service Name
Description
0x0E
Get_Attribute_Single
Returns the contents of the
specified attribute
0x01
Get_Attributes_All
Returns the contents of the
instance or class attributes
defined in the object definition
