Baumer EA Series User Manual

Baumer_EAx_EtherNetIP_EN_MNL 76/81 www.baumer.com
02.20
no name server address
has been configured.
Name Server 2
UDINT
Secondary name
server
Default: 0
Value of 0 indicates that
no secondary name server
address has been
configured.
Domain Name
STRING
Default domain name
Default:""
(ASCII characters)
Maximum length is 48
characters. A length of 0
indicates that no Domain
Name is configured.
6
Get/Set
NV
Host Name
STRING
Host name
Default:""
(ASCII characters.)
Maximum length is 64
characters. A length of 0
indicates that no Host
Name is configured.
10
Get/Set
NV
SelectAcd
BOOL
Activates the use of
ACD
Default: 1
Enable ACD: 1
Disable ACD: 0
11
Get/Set
NV
LastConflictDetected
STRUCT
of:
Structure containing
information related to
the last conflict
detected
ACD Diagnostic
Parameters
AcdActivity
USINT
State of ACD activity
when last conflict
detected
Default: 0
RemoteMAC
Array of 6
USINT
MAC address of
remote node from the
ARP PDU in which a
conflict was detected
Default: 0
ArpPdu
ARRAY
of 28
USINT
Copy of the raw ARP
PDU in which a
conflict was detected.
Default: 0 * 28
ARP PDU
13
Get/Set
NV
Encapsulation
Inactivity Timeout
UINT
Number of seconds of
inactivity before TCP
connection or DTLS
session is close
Default: 120
0 = Disable
1-3600 = timeout in
seconds
