Attribute 5 (Status)
The meaning of the bits of attribute 5 is described in the following table.
Bit(s)
Description
0-3
Not Supported (= 0)
4-7
Extended Device Status (see table below)
8
Minor Recoverable Fault: TRUE indicates the device detected a problem with itself, which
is thought to be recoverable. The problem does not cause the device to go into one of the
faulted states
9
Minor Unrecoverable Fault: TRUE indicates the device detected a problem with itself,
which is thought to be unrecoverable. The problem does not cause the device to go into
one of the faulted states.
10
Major Recoverable Fault: TRUE indicates the device detected a problem with itself, which
caused the device to go into the Major Recoverable Fault state.
11
Major Unrecoverable Fault: TRUE indicates the device detected a problem with itself,
which caused the device to go into the Major Unrecoverable Fault state.
12-15
0
The meaning of bits 4 to 7 (“Extended Device Status”) of attribute 5 is described in the following table.
Value
Description
0
Self-Testing or unknown (not supported)
1
Firmware update in progress (not supported)
2
At least one faulted I/O connection (not supported)
3
No I/O connections established
4
Non-Volatile configuration bad (not supported)
5
Major fault (Bit 10-11 or'ed)
6
At least one I/O connection in run mode (not supported, no run idle data in assemblies)
7
At least one I/O connection established, all in idle mode
8
0
9
Reserved
10-15
0 (not supported)
