MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 109 of 144
The meanings of the annunciater LEDs in operation are given below.
LED
Symbol Name
Pwr Power
MX08 EI is not powered. Check power cable.
MX08 EI is powered.
Lnk Link
No data transmission done.
Data transmission done to xFace or Modbus-RTU
Err Error
No Error found.
Error: Look at the error table in Section 11.6.
Blank Light Flash Blank for 0.3 second
Table 11.1 - Annunciater LEDs
MS Module Status LED
LED State
Description
Off
No power
Green
Controlled by a scanner in run state
Green, flashing
Not configured, or scanner in idle state
Red
Major fault (EXCEPTION state, FATAL error etc.)
Red, flashing
Recoverable fault(s)
LINK/Activity LED
LED State
Description
Off
No link, no activity
Green
Link (100 Mbit/s) established
Green, flickering
Activity (100 Mbit/s)
Yellow
Link (10 Mbit/s) established
Yellow, flickering
Activity (10 Mbit/s)
NS Network Status LED
LED State
Description
Off
No IP address
Green
Online, one or more connections established
(CIP Class 1 or 3)
