MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 26 of 144
This block allows the user to select operation mode and polarity.
Write to Digitizer: Click this button to save the operation mode and polarity.
Calibration block: This block allows the user to make calibration with test weights.
eCal Calibration: This block allows the user to make calibration without test weights.
Figure 3.12 - Calibration
You can find programming and calibration descriptions in Section 4.3.
4.7. Analog Digitizer Performance Testing
MX08 AD performance testing is very important for assuring the stability, weighing speed,
linearity, repeatability and eccentricity of the weighing system.
During testing your system stability and weighing speed, you may change some parameter
values for better performance by using Setup tab.
You can follow the virtual display on the right top, status tab or indicator menu to check the
performance.
