2.3. Housing
MX08 housings are IP20, polyamide and easily mounting on NS 37/7 or NS 35/15
standard DIN rail. Drawings of the housing are seen below.
22,5 mm
45 mm
99 mm
114,5 mm
View A
View B
Side view
MX08 AD
MX08 IO
MX08 MB
MX08 PB
MX08 PN MX08 EN
MX08 EI
MX08 EC
MX08 PL
MX08 DP
View A √ √
View B √ √ √ √ √ √ √ √
Figure 1.3 - Dimensions
