MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 12 of 144
MX08 IO 4 input / 4 output
Input / Output:
Inputs:
4 optic isolated digital inputs
Outputs:
4 free contact outputs. 1A @ 250VAC, 30VDC
Input signal range:
12 VDC to 30 VDC
IO response time:
Typical 4 ms. response delay after read/write commands from field bus
DC Power supply:
24 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 DP Display
Conversion rate:
4 refresh per second
Max. displayed value:
5 digits with overflow indication
Scale functions:
Scale select with scale annunciator
Weighing functions:
Stable, Zero and Net indication
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
