MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 11 of 144
MX08 EI EtherNet/IP
Communication:
Data rate
10 Mbit/s or 100 Mbit/s, full duplex
EDS file
Generic EDS-file provided
DLR (Device Level
Available
TCP/IP settings
DHCP or manual IP assign over EtherX PC Software. Device identity
Topology
Line, Bus, Star or Tree topology depending on physical media
Installation
Switched Ethernet transmission with sh
ielded twisted pair cables and
RJ-45 connectors.
Web client
Available
Isolation
Galvanically isolated bus electronics
Response speed
Typical 4 ms response delay, after read/write commands
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 EC EtherCAT
Communication:
Data rate
100 Mbit/s, full duplex
ESI file
Generic ESI-file provided
Topology
Line, Tree, Star or Daisy-chain topology depending on physical media
Installation
Switched Ethernet transmission with shielded twisted pair cables and
RJ-45 connectors.
Isolation
Galvanically isolated bus electronics
Response speed
Typical 4 ms response delay, after read/write commands
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 PL Powerlink
Communication:
Data rate
100 Mbit/s, half duplex
Compatibility
Supports POWERLINK V2.0 Communication Profile
XDD file
XDD-file provided
Ring redundancy
Available
Topology
100% free choice of star, tree, ring or daisy chain
Installation
Switched Ethernet transmission with shielded twisted pair cables
Isolation
Galvanically isolated bus electronics
Response speed
Typical 4 ms response delay, after read/write commands
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
