MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 10 of 144
MX08 PB Profibus DP
Communication:
Data rate:
Up to 12000 kbit/s with automatic baudrate detection
GSD file
Generic GSD-file provided
Topology:
Depending on physical media
RS-485: segmented line topology without stubs
Installations:
Shielded twisted pair cable
Line length depending on physical media and transmission speed
Max. Stations:
Up to 32 stations per segment, up to 126 stations per network
Isolation:
Galvanically isolated bus electronics
Response delay:
Typical 4 ms response delay, after read/write commands
RS-232C:
9600 baud 8N1, used for service port (xFace)
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 PN Profinet
Communication:
Data rate:
100 Mbit/s, full duplex
GSDML file:
Generic GSDML-file provided
TCP/IP settings:
DHCP or manual IP assign over xFace or Anybus Ipconfig,
Device identity customization
Topology:
Line, Bus, Star or Tree topology depending on physical media
Installation:
Switched Ethernet transmission with shielded twisted pair cables and
RJ-45 connectors.
Isolation:
Galvanically isolated bus electronics
Response delay:
Typical 4 ms response delay, after read/write commands
RS-232C:
9600 baud 8N1, used for service port (xFace)
DC Power supply:
11 to 28 VDC max. 300 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 EN Ethernet
Communication:
Transmission rate:
10 Mbit/s, half duplex
Response delay:
Typical 4 ms response delay, after read/write commands
TCP/IP settings:
Manual IP assign over xFace
Installation:
Switched Ethernet transmission with shielded twisted pair cables
Web client:
MX08 system is presented over web page
RS-232C:
9600 baud 8N1, used for service port (xFace)
DC Power supply:
11 to 28 VDC max. 300 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
