MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 51 of 144
7.4. Error Table
The MX08 IO instruments have been designed as very reliable and virtually error free
instruments. However if an error occurs do not attempt to repair the equipment before you
understand what caused the error. Note the problems you have with your instrument and
the error messages shown by the LEDs located on the front panel. Then try to solve the
problem according to the error table given below.
Error Code Description Actions to take / Possible cause
Pwr Link Err
System Error
− Re-
energize the instrument. If seen again, change
the board.
Configuration
Error
− Re-address the instruments on N-Bus (
section 3.3 or Section 3.9 N-Bus addressing).
N-Bus
Communication
Error
− Check the Gateway instrument whether it is in
system and powered on.
−
Check the internal bus connector whether it is
installed on the rail.
Blank Light Flash Blank for 0.3 second
Table 6.2 - Error Table
