2.2. Key features and specifications
MX08 AD Analog Digitizer
A/D Converter:
A/D converter type:
24 bit Delta-Sigma radiometric with integral analog and digital filters
Conversion rate:
Up to 800 measurements per second
Input sensitivity:
0.1 μV/e (non approved)
Analog input range:
0 mV to +18 mV ( unipolar ) ;
- 18 mV to +18 mV ( bipolar )
Internal resolution:
up to 8 000 000
External Resolution:
Count mode
1 000 000 count in unipolar signal range
2 000 000 count in bipolar signal range
Weighing and Force
mode
up to 100 000 increment
Scale Calibration and Functions:
Calibration:
Calibration is performed with or without etalon weights via xFace or
field bus
Digital filter:
10 steps programmable adaptive filter
Weighing functions:
Taring, zeroing, auto zero tracking, motion detection, auto zero at
power up, save tare at power-off, increased resolution
Linearity:
Within 0.0015% FS, ≤ 2 ppm/°C
Load cells:
Excitation:
5 VDC max. 100 mA
Number of load cells:
Up to 6 load cells 350 Ω or 18 load cells 1100 Ω in parallel
Connection:
4- or 6-wire technique.
Cable length: maximum 250 m/mm² for 6-wire connection
DC Power supply:
12 to 28 VDC max. 200 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
MX08 MB Modbus-RTU
Communication:
RS-485:
1200 to 57600 baudrate, 8N1,7E1,7O1
RS-232C:
9600 baudrate, 8N1
Response delay:
Typical 4 ms response delay, after read/write commands
Max Stations:
Up to 31 stations per segment
DC Power supply:
11 to 28 VDC max. 100 mA
Environment and Enclosure:
Operation temp.:
-10 °C to +40 °C; 85% RH max, non-condensing
Enclosure
Polyamide, mounting in standard DIN rails, IP20
