MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 133 of 144
The meanings of the annunciater LEDs in operation are given below.
LED
Symbol Name
Pwr Power
MX08 PL is not powered. Check power cable.
MX08 PL is powered.
Lnk Link
No data transmission done.
Data transmission done to xFace or Modbus-RTU
Err Error
No Error found.
Error: Look at the error table in Section 9.6.
Blank Light Flash Blank for 0.3 second
Table 13.1 - Annunciater LEDs
STS Status LED
LED State
Description
Off
Module is off, initializing, or not active.
Green, fast flashing
a
NMT_CS_BASIC_ETHERNET
Bas
ic Ethernet state: no POWERLINK traffic has been
detected.
Green, single flash
NMT_CS_PRE_OPERATIONAL_1.
Only asynchronous data.
Green, double flash
NMT_CS_PRE_OPERATIONAL_2.
Asynchronous and synchronous data. No PDO data.
b
Green, triple flash
NMT_CS_READY_TO_OPERATE.
Ready to operate. Asynchronous and synchronous data. No
PDO data.
b
Green
NMT_CS_OPERATIONAL.
Fully operational. Asynchronous and synchronous data. PDO
data is sent and received.
Green, slow flashing
c
NMT_CS_STOPPED
Module stopped (for
controlled shutdown, for example).
Asynchronous and synchronous
data. No PDO data.
b
Red
If the ERROR LED also is red, a fatal event was encountered.
a. On 50 ms, off 50 ms.
