MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 56 of 144
Response Speed
Response speed can be selected as “immediate” or “20 msec” for Modbus RTU data
format.
Immediate : Mod
bus RTU Answer is sent immediately after Request is
received.
20 msec :
Modbus RTU Answer is delayed 20 msec after Request is
received.
This property is very helpful for slow PLC systems.
Default is ‘immediate’.
RS-485 Data Format
This parameter programs the RS-485 communication port data format. The available data
formats are;
Disable
:
No data will be transmitted. Select disable if this port is not used.
BSI :
Communicates in BSI data format as a slave. Refer to ‘Refer to
Section 3.11’ for details.
Modbus RTU
High-Low
: Modbus RTU communication. Refer to Section 7.5 for details.
Modbus RTU
Low-High
: Modbus RTU communication. Refer to Section 7.5 for details.
Note: xFace automatically connects to the instrument whatever the data format is. After
xFace disconnection, the instrument returns to run with last saved data format.
RS-485 Baud rate
One of the following baudrate is selected for RS-485 communication port.
1200
2400
4800
9600
19200
38400
57600
Default is ‘9600’.
RS-485 Data Length & Parity
The data length and parity can be selected as 8 None 1, 7 Odd 1 or 7 Even 1.
Default is ‘8 None 1’.
