MX08 Multichannel Weighing System, Technical Manual, Rev. 2.5 Page 81 of 144
The meanings of the annunciater LEDs in operation are given below.
LED
Symbol Name
Pwr Power
MX08 PN is not powered. Check power cable.
MX08 PN is powered.
Lnk Link
No data transmission done.
Data transmission done to xFace or Modbus-RTU
Err Error
No Error found.
Error: Look at the error table in Section 9.6.
Blank Light Flash Blank for 0.3 second
Table 9.1 - Annunciater LEDs
MS Module Status LED
LED State
Description
Comment
Off Not power or not initialized
No power or profinet module is
in initialization state
Green Initialized
Green, 1 flash
Initialized, diagnostic event(s)
present
Diagnostic is active
Red Exception error There is an exception error
Red, 1 flash Configuration Error Check GSDML configuration
Red, 2 flashes IP Address Error IP address not set
Red, 3 flashes Station Name Error Station name not set
Red, 4 flashes Internal Module Error
Re-energize the instrument.
If seen again, change the board.
LINK/Activity LED
LED State
Description
Comment
Off No Link
No link, no communication
present
Green Link
Ethernet link established, no
communication present
Green, flickering Activity
Ethernet link established,
communication present
