2 – Installation
37
Hospital Service Field (33) checkbox
The default setting is checked.
9000 Legacy Mode
The default setting is unchecked.
The following fields are used to define the expected characters in LIS messages.
SOH
The default setting is 0x01.
EOT
The default setting is 0x04.
ACK
The default setting is 0x06.
NAK
The default setting is 0x15.
CAN
The default setting is 0x18.
SYN
The default setting is 0x16.
LIS Communications Buttons:
Select to clear changes and return to saved values. Only active if field values are changed and
are not saved.
Select to save changes. When the Enter Password window appears, select the blank
password field. Enter the Supervisor password with the onscreen keyboard, then select
ENTER, followed by OK.
This button appears only if Log Comms is enabled.
Select to print all the LIS messages in the Event Log. The messages include the time stamp
when the message was generated.
Undo button
Save button
Print button
