2 – Installation
33
Select the volume of the instrument's Positive Vial audible alarm. The default setting is 5,
which is at the middle of the volume range. To increase or decrease the volume, select the Up
or Down Arrow to increase or decrease the value in the field from 1 (softest) to 10 (loudest).
To hear a sample of the current volume, select Volume.
This setting also affects the volume of the optional Remote Alarm unit.
The volume of other instrument audible alarms is controlled by the system software and
cannot be adjusted.
Address
Read-only fields showing network configuration information. ID shows the original MAC
address of the Network Interface Card in the instrument. NIC shows the current MAC address
of the Network Interface Card in the instrument. IP shows the Internet Protocol address for the
instrument.
Serial Numbers
Read-only fields showing the instrument Serial Numbers. This number is set at instrument
installation. Top represents the high instrument in the stack, and Bottom represents the low
instrument. If there is only one instrument, only Top is shown.
Configuration – Instrument Buttons:
Select to clear changes and return to saved values. Only active if field values are changed and
are not saved.
Select to save changes. When the Enter Password window appears, select the blank
password field. Enter the Supervisor password with the onscreen keyboard, then select
ENTER, followed by OK.
2.4.4 LIS Configuration
LIS configuration enables you to set up communications with a Laboratory Information System (LIS).
Communications should only be enabled/disabled by a BD representative.
To modify default values, refer to the field requirements listed below. When changes are complete,
select Save.
LIS WIndow fields:
Disabled radio button
To disable all communications with the LIS, select the Disabled radio button. This button is
selected by default.
Volume
Undo button
Save button
