9
B. Put the foot pedal unit(4) in
between the left and right legs
components (2&3), use 4
pieces of screws (8)(2 on each side)
to stable the legs onto the foot
pedal unit. (Make sure the
direction of the placement is
correct before screwing)
C. Use 4 pieces screw (9) & 2 pieces
screw (12) make the Rear board
fixed on the foot pedal by screw (9),
Left and right legs component
by screw (12) finished in part B
on the previous page.
Set Up
To Next Page
