10
D. Put the piano body (1) on the
top of the assembly completed
in part B, use two hand screws
(7) and two M6x18 screws (6) to
stabilise afterwards.
Set Up 2
E. After the initial set-up, connect
pedal cable (11) in the foot pedal
unit to the bottom-panel
PEDAL jack.
