Installation
Configuration Setup
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 61
Display Contents
Description
DYN MIKE
Dynamic microphone input (Pins P1-6/ P1-5) is selected
NONE
No microphones is used in microphone path 2
"MIC ACTIVATION"
BOTH MIKES ENABLED:
Input /PTT1 (Pin P1-17) activates transmission from microphone path 1
and 2
Input /PTT2 (Pin J1-5) activates transmission from microphone path 2
and 1
Input /IC (Pin P1-7) activates intercom from microphone path 1 and 2
BOTH MIKES DISABLED:
Input /PTT1 (Pin P1-17) activates transmission only from microphone
path 1
Input /PTT2 (Pin J1-5) activates transmission only from microphone
path 2
Input /IC (Pin P1-7) activates intercom only from microphone path 1
"OUTPUTS"
HDPH 1 ENABLED
Audio available on headphone 1 output (Pins P1-2/P1-3)
HDPH 1 DISABLED
No audio is available on headphone 1 output.
HDPH 2 ENABLED
Audio is available on headphone 2 output (Pins P1-20/P1-22), speaker
not available.
HDPH 2 DISABLED
No audio available on headphone 2 output, speaker not available.
SPEAKER ENABLED
Audio is available on speaker (Pins P1-1/P1-14), headphone 2 not
available
NONE
No audio on headphone 2 output or speaker output.
Note: Menu available on primary controller.
Displayed only if MIKE_SW input (Pin J1-24) has inactive state.
Display Contents
Description
"STD1 MIKE SENS":
The sensitivity of standard microphone 1, "STD 1 MIKE SENS", input is
adjustable within the range 9...1500 mV by turning the "ROTARY
ENCODER".
