Becker AR620X - Page 65

Installation
Configuration Setup
DV14307.03 Issue 04 March 2016 Transceiver Family 620X 65
Display Contents
Description
Note: Menu available on primary controller.
"SCAN HOLD TIME":
The "SCAN HOLD_TIME" is adjustable within the range of
1...60 seconds by turning the "ROTARY ENCODER".
1
SCAN HOLD TIME
The default factory setting is 1.
Note: Menu available on primary controller.
For normal airborne operation it is recommended to leave the
setting at 1.
"SIDETONE ATT":
The sidetone attenuation "SIDETONE ATT" is adjustable within the
range 0…12 dB by turning the "ROTARY ENCODER".
6
SIDETONE ATT
The attenuation relates to the intercom volume.
0dB = sidetone as loud as intercom signal.
12dB = sidetone signal 12 dB less than the intercom signal.
Example: If the intercom volume is set to a very low value, then the
sidetone volume will be reduced in relation to the intercom volume,
irrespective of the sidetone value.
The "SIDETONE ATT" parameter is an additional attenuation of the
sidetone signal in transmit mode.
Note: Menu available on primary controller.
"ERASE CHN MEM":
The 620X transceiver provide two databases to store up to 99 VHF
frequencies identified by channel numbers (CH01 to CH99).
Both data bases, the "User Channels Database" and "Last Channels
Database" can be erased.
NO
YES
ERASE CHN MEM
To erase the data bases;
1. Select "YES" via the "ROTARY ENCODER"
2. Press the "STO" push-button to confirm the selection.
Note: Menu available on primary controller.
