Commissioning
EL72x1130 Version: 3.3
6.5 MDP742 process data
Table of contents
• Sync Manager [}130]
• PDO Assignment [}131]
• Predefined PDO Assignment [}132]
Sync Manager (SM)
Sync Manager (SM) The scope of the offered process data can be changed via the "Process Data" tab (see
Fig. "Process Data tab SM2, EL72x1 (default), Process data tab SM3, EL72x1 (default)").
Fig.160: Process Data tab SM2, EL72x1 (default)
