Commissioning
EL72x1 81Version: 3.3
Advanced The Advanced button opens the Advanced Settings
dialog. Here you can specify which objects are
displayed in the list.
Fig.96: Dialog “Advanced settings”
Online - via SDO Information If this option button is selected, the list of the objects
included in the object list of the slave is uploaded
from the slave via SDO information. The list below
can be used to specify which object types are to be
uploaded.
Offline - via EDS File If this option button is selected, the list of the objects
included in the object list is read from an EDS file
provided by the user.
„Online“ tab
Fig.97: „Online“ tab
