Monthly Maintenance
Replace Alkaline Buffer
Maintenance UniCel DxC Systems Instructions For Use A13914
Page 10-26 October 2005
3 Press the latch, which is located on the connector (1), to disengage the
electrode pin lead from the connector panel and remove the electrode
connector from the socket.
Figure 10.12
4 Unscrew the BUNm/UREAm electrode retainer nut (1) and withdraw the
electrode-retainer assembly from the chemistry reaction cup.
Figure 10.13
Step Action, continued
(2 of 5)
