Partitions Select the Keypad Partitions. The Keypad
will be able to control (Arm, Disarm, etc.) ONLY the En
-
abled Partitions.
+
Keypads need not necessarily be enabled on Parti
-
tions, and can be used for programming, viewing
and other non-command related purposes.
n
Expander In
The Expander In option group will allow you to enroll the
Input Expanders located on the M-IN/OUT Expanders
the PREMIUM and the ABSOLUTA T-Line keypads
connected to the BPI bus
1
.
+
For information regarding the Enabled and Label
options, refer to “Configuration”.
Inputs Select the number of inputs on board the de
-
vice: only the relevant terminals will therefore be dis
-
played in the Zones option group.
n
Expander Out
The Expander Out option group will allow you to enroll
the Output Expanders located on the M-IN/OUT Ex
-
panders, on the PREMIUM and ABSOLUTA T-Line
keypads, connected to the BPI bus
1
.
+
For information regarding the Enabled and Label
options, refer to “Configuration”.
Outputs Select the number of outputs on board the de-
vice: only the relevant terminals will therefore be dis-
played in the Outputs option group.
n Key Readers
The Key Readers option sub-group will allow you to en-
roll and set up Key Readers. You must set up the Op-
tions and the Arm Modes for each Partition, as follow.
+
For information regarding the Enabled and Label
options, refer to “Configuration”.
EN50131 If this option is enabled, in standby mode the
Readers’ LED’s are turned off, regardless of the Parti
-
tion status.
Default: enabled.
A
In order to comply with the EN50131-1 and
EN50131-3 standards, this option must be en
-
abled.
3
This option is ENABLED and locked (cannot be
changed) on Grade 3 Control Panels.
Partitions This option will allow you to assign the
Reader to the relevant Partition: the Reader will be able
to Arm the Partition in Away mode.
+
Commands performed by the selected Key Reader
will affect ONLY the Partitions common to both the
Reader and Key in use.
For example, if you attempt to Arm the system at a
Reader that is enabled on Partitions no. 1 and no. 2,
with a Key that is enabled on Partitions no. 1 and no. 3,
ONLY Partition no. 1 will Arm (Partition no. 1 is common
to both the Reader and Key).
Yellow This option will allow you to set up the A Mode
Arming configuration. If an A Mode Arming request is
made at a Reader, the Partitions will Arm/Disarm in ac
-
cordance with the programmed configuration, as
follows:
Ø
None — the status of the corresponding Partition
will remain unchanged;
Ø
Away Arm — the Partition will Arm;
Ø
Stay Arm — the Partition will Arm in Stay mode (i.e.
Zones with the Internal Attribute will be Bypassed);
Ø
Instant Stay — the Partition will Arm in Stay mode
with zero Entry Delay;
Ø
Disarm — the Partition will Disarm.
Green As per the Yellow option but for B Mode.
n Power station
The Power stations page will allow you to enroll and
setup the Power Stations.
+
For information regarding the Enrolled and Label
parameters, refer to the “Configuration” section.
AC Fail Delay Set the delay for the MAINS fault on the
Power Supply Station before it will be signalled.
Valid entries: 0 through 3600 seconds, in 1 second steps.
Default setting: 0 seconds
A
In order to comply with the EN50131-6 standards,
this option MUST NOT be more then 60 seconds.
Low Battery Delay Set the delay for the low battery on
the Power Supply Station (battery voltage below 11.4 V)
before it will be signalled.
Valid entries: 0 through 3600 seconds, in 1 second step.
Default setting: 0 seconds
A
In order to comply with the EN50131-6 standards,
this option MUST NOT be more then 300 seconds.
ABSOLUTA PROGRAMMING FROM THE PC 41
1 The M-IN/OUT Expander is seen as an Input Expander and/or as an Output Expander, depending on how it is
programmed (refer to the M-IN/OUT’s instructions for more information). If the M-IN/OUT Expander is programmed
as an Input and Output Expander, it must be enrolled as an Input Expander and as an Output Expander. For
example, if you have programmed an M-IN/OUT Expander as an Input Expander and Output Expander, and
assigned it address no. 1, you must enroll Input Expander no. 1 and Output Expander no. 1.
