How Downloading/Uploading the Options
Once you have set up the connection, you can Down
-
loading/Uploading the options as follow.
+
Downloading is the operation that transfers data
from PC to Control Panel.
Uploading is the operation that transfers data from
Control Panel to PC.
1. Either select the options to Downloading/Uploading
by enabling the relative Downloading/Uploading
Tabs or jump to the next step to Down
-
loading/Uploading ALL the options (Global Down
-
loading/Uploading):
Ø
the tag ( ) means that the relative option neither will
be uploaded nor downloaded;
Ø
the blue tag ( ) means that the relative option will
be uploaded;
Ø
the red tag ( ) means that the relative option will be
downloaded.
You can enable all the group options to be up
-
loaded/downloaded by clicking on the / icon.
You can clear all the group option tags by clicking on the
icon on the Group toolbar.
You can clear option tags of all Groups by clicking on
the icon on the Main toolbar.
2. Either click on the icon to start the Down-
loading/Uploading of the selected options or click
on the / icon to Downloading/Uploading ALL
the options.
+
The Global Downloading does not download Voice
messages, the Voice Message Labels, the Key
codes and PINs
27
.
The Global Uploading does not upload Voice mes
-
sages, the Voice Message Labels, the Key codes,
the PINs
26
and Event Log
28
.
The application shows the Communicate Tags,
Global Dowload or Global Upload window.
3. Select the Connection Type.
4. Ensure the Access Code is the same as the Con
-
trol Panel Installer PIN (factory setting: 0104) and
the Identifier is correct (see System Options >
General > Panel Identifier Code).
5. Click OK.
86 Expandable Hybrid Control Panel
27The PIN can be downloaded/uploaded if the user has enabled the “PIN transfer” option (see “Codes and Keys: User
28The Event Log can be uploaded, if the Events Log option is enabled in the Global Upload window, and from the
Event Log page
