Disable code if duplicated PIN If the Auto PIN Gen
-
eration option is disabled it may transpire that when a new
PIN is programmed it is the same as another PIN in the
system; in this case system security will be compromised.
If this option is ENABLED the used PIN is disabled and
can only be re-enabled by a Master PIN enabled in the
same Partitions as the used PIN.
The duplicated PIN is flagged by:
Ø
the Duplicated PIN fault;
Ø
the Duplicated and Discovered PIN event.
+
The used PIN and the PIN which detected it are
stored in the events log.
+
This option is disabled and locked if the Auto PIN
Generation option is ENABLED.
Default: disabled.
Receiver Channel Prioity Select the channel for
transmitting events to the Sur-Gard SYSTEM I, II or III
receivers, as outlined below.
Ø
GPRS Only: the GPRS channel ONLY will be used.
Ø
IP Only: the IP channel ONLY will be used.
Ø
GPRS Primary, IP Backup: the IP channel will be
used in the event of a GPRS channel failure.
Ø
IP Primary, GPRS Backup: the GPRS channel will
be used in the event of an IP channel failure.
Default: IP Primary, GPRS Backup.
n Time Options
Date / Time Set Date and the Time of the Control
Panel.
+
Date and Time can be programmed also by keypad.
Periodic Test Transmission time Set the date and
the time of the first Periodic Test.
Periodic Test Transmission interval Set the time
that must elapse between a Periodic Test and the next.
Valid entries: 0 through 65,535 minutes.
A
In order to comply with the EN50136-2-1 standards,
the option Periodic Test Transmission should
ENABLED and the Periodic Test Transmission
interval MUST NOT be more then 1,500 minutes
(25 hours) for Grade 2 Control Panels with ATS2
and 180 s for Grade 3 Control Panels and ATS5.
Installer Maintenance Time Set the date and the time
of the first Installer Maintenance event.
Installer Maintenance Interval Set the time that must
elapse between a Installer Maintenance event and the
next.
Valid entries: 0 through 65,535 minutes.
Surveillance Maintenance Time Set the date and the
time of the first Surveillance Maintenance on Panel event.
Surveillance Maintenance interval Set the time that
must elapse between a Surveillance Maintenance on
Panel event and the next.
Valid entries: 0 through 65,535 minutes.
Daylight saving time/Daylight saving time - restored
If required, change the date and hour for Summer time
begins/ends:
Ø
the Panel moves 1 hour forward its clock, on date
and time set for the Daylight saving time options;
Ø
the Panel moves 1 hour back its clock, on date and
time set for the Daylight saving time - restored op
-
tions;
The system will signal Automatic Changeover by:
Ø
switching ON the G LED.
+
The G LED signals several different types of Trouble
events. If signalling is due to the Standard time/Sum
-
mer time changeover, the Keypad (in View Trouble
Mode) will show the summer time message.
Default: the Panel moves its clock 1 hour forward at 2
AM of the last March’s Sunday and 1 hour back at 3 AM
of the last October’s Sunday, until 2030.
n
Received Call
Number of Rings Set the number of rings the Control
panel must allow before answering an incoming call.
+
If the Double call option is enabled, the Number of
Rings will be ignored (refer to “Double call” below).
Double Call Enable This option will allow the Control
Panel to share the telephone line with another answer-
ing device (answering machine, fax, etc.). Under nor-
mal circumstances, the device which allows the least
number of rings will answer any incoming calls. How-
ever, if this option is Enabled, the Control panel will
override the other answering device when it recognizes
the Double Call sequence.
Double Call sequence: the caller must allow no more than
2 rings, then hang up and callback within 60 seconds. The
Control panel will answer on the first ring of the second call.
+
The other answering device must be programmed
to answer after 3 or more rings.
n
Phone Options
Call Confirmation If this option is enabled, the Con
-
trol Panel will not consider a call successful until the call
receiver presses the star key on the telephone keypad,
in order to generate a feedback signal.
Default: Enabled.
+
If this option is enabled, you should include a re
-
quest for the feed back signal (press star) in the
message.
56 Expandable Hybrid Control Panel
