Control Panel versions
You can create the Control Panels listed below, by assem
-
bling the available components, as shown in the Table 2.
ABS16P15 Up to 8 Zone Control Panel, expandable
up to 16 zones, in Plastic Box with 1.5 A Power Supply.
ABS16P35 Up to 8 Zone Control Panel, expandable
up to 32 zones, in Plastic Box with 2.6 A Power Supply.
ABS42P15 Up to 8 Zone Control Panel, expandable
up to 42 zones, in Plastic Box with 1.5 A Power Supply.
ABS42P35 Up to 8 Zone Control Panel, expandable
up to 42 zones, in Plastic Box with 2.6 A Power Supply.
ABS42P50 Up to 8 Zone Control Panel, expandable
up to 42 zones, in Plastic Box with 3.6 A Power Supply.
ABS104P50 Up to 8 Zone Control Panel, expandable
up to 104 zones, in Plastic Box with 3.6 A Power Supply.
ABS16M35 Up to 8 Zone Control Panel, expandable
up to 16 zones, in Metal Box with 2.6 A Power Supply
ABS42M50 Up to 8 Zone Control Panel, expandable
up to 42 zones, in Metal Box with 3.6 A Power Supply.
ABS42M75 Up to 8 Zone Control Panel, expandable
up to 42 zones, in Metal Box with 5.4 A Power Supply.
ABS104M50 Up to 8 Zone Control Panel, expandable
up to 104 zones, in Metal Box with 3.6 A Power Supply.
ABS104M75 Up to 8 Zone Control Panel, expandable
up to 104 zones, in Metal Box with 5.4 A Power Supply.
n
Grade 3 Control Panels
The Control Panels listed below are shipped partially
assembled and adopt some measures that make them
compliant with Grade 3 of the EN50131 standard.
3
Since this manual is common to all Control Panel
versions, this note will be used to highlight the spe
-
cific characteristics of Grade 3 Control Panels.
In addition, from time to time specific characteristics of
Grade 2 and Grade 3 Control Panels will be highlighted.
ABS16M50-G3 Up to 8 Zone Control Panel, expandable
up to 16 zones, in Metal Box with 3.6 A Power Supply.
ABS104M75-G3 Up to 8 Zone Control Panel, expandable
up to 104 zones, in Metal Box with 5.4 A Power Supply.
The packaging of the control panels listed above in
-
cludes the following components:
Ø
the backplate with tamper and wall-tamper switches
mounted;
Ø
the Cover;
Ø
the ABS16 or ABS104 Main board depending on the
Control Panel;
Ø
1 identification label of the type of Control Panel;
Ø
the BAW50T12 or BAW75T12 Switching Power Supply;
Ø
5 12 mm plastic supports for the Main board;
Ø
8 10 mm plastic supports for two input/output ex
-
panders;
Ø
1 12 cm earth wire (Yellow-Green) with eyelet;
Ø
1 plastic wall-tamper bracket;
Ø
2 (1 x 3 mm) cogged metal washers;
Ø
1 self tapping screw 3 x 6 mm to secure the Earth
wire (Yellow-Green) with eyelet;
Ø
1 (3 x 8 mm) screw to secure the power supply;
Ø
2 adapters for connecting the battery 17 Ah;
Ø
1 40 cm cable for connecting the battery;
Ø
17 10 Kohm resistors (brown/black/orange/gold), 16
for Single and Double Supervision of the Zones and
1 for the Supervision of the Tamper Line;
Ø
9 2.2 Kohm resistors (red/red/red/ gold), 8 for Triple
Supervision of the Zone, 1 for supervision the +A
Output;
Ø
8 8.2 Kohm resistors (grey/red/red/gold) for Triple
Supervision of the Zone;
Ø
8 22 Kohm resistors (red/red/orange/gold) for Triple
Supervision of the Zone;
Ø
1 Quick User Guide (Italian/English/Spanish/Portu
-
guese/French);
Ø
1 Quick User Guide (English/German/Swed
-
ish/Dutch/Danish).
n The boxes
The following Boxes are available for the ABSOLUTA
Control Panels.
ABS-P Is a plastic box that supports the ABS16,
ABS42 and ABS104 Main Boards, and the 1.5 A, 2.6
and 3.6 A Power Supplies. In addition it can house a
backup battery up to 7Ahand an M-IN/OUT Input/Out-
put Expander Module. The Plastic Box package in-
cludes the following parts:
Ø
the Backplate with the tamper switch mounted;
Ø
the Cover;
Ø
1 21 cm earth wire (Yellow-Green) without eyelet;
Ø
2 self tapping screws — 3.5 x 12 mm to secure the
Cover;
Ø
5 3 x 8 mm Parker screws (2 to secure the main
board, 2 to secure the power supply and 1 to secure
the possible input/output expander;
Ø
2 “Premises protected” Labels (English and Italian).
ABS-M Is a metal box that supports the ABS16, ABS42
and ABS104 Mother Boards, and the 2.6 A, 3.6 A and
5.4 A Power Supplies. In addition it can house a backup
battery up to 17 Ah and up to two M-IN/OUT Input/Output
Expander Modules. The Metal Box package includes the
following parts:
Ø
the Backplate;
Ø
the Cover;
Ø
5 12 mm plastic supports for the Main board;
Ø
8 10 mm reverse locking supports for two Input/Out
-
put Expanders;
Ø
1 12 cm Earth wire (Yellow-Green) with eyelet;
Ø
1 plastic wall-tamper bracket;
Ø
2 (1 x 3 mm) cogged metal washers;
Ø
2 M4x8 mm metric screws to secure the Cover.
8 Expandable Hybrid Control Panel
