Ø
1 3 x 6 mm metric screw to secure the Earth wire
(Yellow-Green) with eyelet;
Ø
23x8metric screw to secure the power supply;
Ø
2 adapters for connecting the battery 17 Ah;
Ø
1 Tamper switch;
Ø
2 3 x 5.5 mm nuts for fixing the tamper switch in place;
Ø
2 “Premises protected” Labels (English and Italian);
Ø
1 “BENTEL – Security Systems” CD.
n
The Main Boards
The following Main Boards are available for the
ABSOLUTA Control Panels.
ABS16 Up to 8 zone Main Board, expandable up to 16
zones.
ABS42 Up to 8 zone Main Board, expandable up to 42
zones.
ABS104 Up to 8 zone Main Board, expandable up to
104 zones.
The Main Board package includes the following parts:
Ø
the Main Board;
Ø
1 identification label of the type of Control Panel;
Ø
1 40 cm cable for connecting the battery;
Ø
17 10 Kohm resistors (brown/black/orange/gold), 16
for Single and Double Supervision of the Zones and
1 for the Supervision of the Tamper Line;
Ø 1 2.2 Kohm resistors (red/red/red/gold) for supervi-
sion of Output +A;
Ø 1 Quick User Guide (Italian/English/Spanish/Portu-
guese/French);
Ø 1 Quick User Guide (English/German/Swed-
ish/Dutch/Danish).
n The Power Supplies
The following Power Supplies (Type A - EN50131-6)
are available for the ABSOLUTA Control Panels.
BAQ15T12 1.5 A @ 13.8 Vdc Switching Power Supply.
BAW35T12 2.6 A @ 13.8 Vdc Switching Power Supply.
BAW50T12 3.6 A @ 13.8 Vdc Switching Power Supply.
BAW75T12 5.4 A @ 13.8 Vdc Switching Power Supply.
+
Read the Power Supply’s instructions for more in
-
formation.
n
The Accessories
The following accessories are available to improve the
performances of the ABSOLUTA Control Panels.
MAXIASNC Switch for open/removal detection.
KST Thermal Probe.
n
Plug-In Modules
The following plug-in modules can be installed inside
the ABSOLUTA box to expand the capability of the
Control Panel.
M-IN/OUT Input/Output Expander.
ABS-GSM GSM Module.
ABS-IP IP Module.
ABSOLUTA INTRODUCTION 9
ABS-IP IP Module
ABS-VAP11N WiFi Bridge
ABS-GSM GSM Module
BGSM-100CA GSM Antenna for metal box (ABS-M)
ABS-AK GSM Antenna for plastic box (ABS-P)
ANT-EU External GSM Antenna
M-IN/OUT 6 Input/Output Expander
ABSOLUTA
M-Touch
Touchscreen Keypad
ABSOLUTA
T-Black
LCD keypad with Input/Output
Expander and Proximity Reader
on-board, black
ABSOLUTA
T-White
LCD keypad with Input/Output
Expander and Proximity Reader
on-board, white
PREMIUM LCD
LCD Keypad with Input/Output
Expander and Proximity Reader on
board
CLASSIKA LCD LCD Keypad
ECL2-UKR
(ECLIPSE2)
Recessed Universal Reader
Module for Proximity Key
ECL2-C
(ECLIPSE2)
Cover for ECL2-UKR Universal
Reader Module
PROXI
Indoor/Outdoor Proximity Reader
(IP34), for Proximity Key
SAT Proximity Key
SAT2 Proximity Key
PROXI-CARD Proximity Card
MINIPROXI Proximity Tag
PROXI-TAG/B Black Proximity Tag
PROXI-TAG/G Gray Proximity Tag
PROXI-TAG/W White Proximity Tag
AS100
Microphone + Loudspeaker
Station
BRM04/12
4-Relay module for open-collector
outputs
BXM12/30-B 3.6 A BPI Power Supply Station
BXM12/50-B 5.4 A BPI Power Supply Station
VRX32-868 868 MHz KEYBUS Receiver
VRX32-433 433 MHz KEYBUS Receiver
VRX32-433EN 433 MHz KEYBUS Receiver
VRP-433 433 MHz Repeater
MAXIASNC Big NC Tamper Switch
KST Thermal Probe
USB5M 5 m USB Cable
BOSS Console Software
Table 3 Compatible items.
