Options-Real Time If this option is disabled (default),
the zone alarm event ends when the system alarm time
expires.
If this option is enabled, the zone alarm event ends
when the zone goes back to standby status.
Options-Active On Keypads If this option is enabled,
the zone activation generates a message on the keypads
associated to the partitions the zone is assigned to.
+
The message is displayed ONLY on keypads with
option EN50131 disabled.
Options-Check Inactivity If this option is enabled, the
Control Panel check the inactivity on the Zone.
+
Refer to the Delinquency option on the Partition
Group for more information.
Partitions This option will allow you to assign the
Alarm and Command Zones to the Partitions.
Ø
For Alarm Zones, will determine which User PINs,
Keys and Operating Times will be associated with the
Zone. Each Alarm Zone can be assigned to more than
one Partition.
+
If the Zone is a Delayed Zone (Entry Delay, Path,
Exit Delay or Last Exit Delay), the system will apply
the longest Entry Delay, Exit Delay or Last Exit De-
lay of all its Armed Partitions.
Ø For Command Zones, will determine which Parti-
tions the Zone will be able to control. Each Com-
mand Zone can operate on more than one Partition.
Partitions
Each Partition consists of a group of zones that the
Control Panel manages independently (Virtual Control
Panel). Each Partition can be programmed with its own
Codes, Timers, Actions and Parameters.
This Control Panel manages 16 Partitions. You can
setup the Partitions in the Zones group.
The Partitions group allows you to set up the options
for the zones, as described below.
The first column shows the Partition Identification Num
-
ber.
Label This option is for the Partition Label (16 charac
-
ters). The Partition Label will identify the Partition in all
the operations it is involved in.
SMS Label Enter a code to identify the Partition in the
operations via SMS (see “USER MNUAL > SMS
OPERATIONS”).
Valid values: up to 5 characters.
Default: the identification number of the Area.
Time-Entry Delay Any partition can have an Entry
Delay, during which the Entry Path and the Entry De
-
lay zones are not able to alarm the partition. This time
starts when the partition is armed in Stay or Away
mode, and an Entry Delay zone is violated.
The Partition Entry Delay will be signalled by:
Ø the Entry Delay on partition event for the Partition;
Ø an audible signal from the Partition Keypads.
The duration of the timer should be programmed to
have enough time to reach the point in which the parti-
tion can be disarmed.
Ø The valid range is 15 to 3600 seconds
Ø The default setting is 30 seconds.
Time-Exit Delay Any partition can have an Exit Delay,
during which the Exit Delay zones are not able to alarm
the system. This time starts when the partition is armed
in Stay or Away mode. At the end of the Exit Delay the
Exit Delay zones becomes Instant zones.
The Partition Exit Delay will be signalled by:
Ø
the Exit Delay on partition event for the respective
Partition;
Ø
an audible signal on the Partition Keypads;
Ø
The valid range is 15 to 3600 seconds;
Ø
The default setting is 30 seconds.
Time-Last Exit Time Violation of an Armed Last Exit
Zone will trigger the programmed Last Exit Time of its
Partition. This feature will allow the system to Arm as
soon as the programmed Last Exit Time expires.
Ø
Valid entries: 5 through 3600 s, in 1-s steps.
Ø
If you enter a higher value, it will be converted auto
-
matically to the maximum admissible value.
Ø
Default setting: 15 seconds.
