Part mask Zn001
*---------------
4. Set up the Zone Partitions as follow.
Ø
Press a to assign ALL the Partitions to the Zone.
Ø
Press b to assign none Partition to the zone.
Ø
Press c and d to scroll the Partitions: a blinking char
-
acter indicates the currently selected Partition.
Ø
Press ON to assign the selected Partition to the
Zone.
Ø
Press OFF to NOT assign the selected Partition to
the Zone.
Ø
Press ENTER to confirm the Zone Partitions or ESC
to discharge the changes, and go back to step 1.
Part mask Zn001
*--------------*
In the top example, Zone 1 is assigned to the Partitions
1 and 16.
n
Partition
Panel Prog.
Partition Pt---
The Partition option let you to set up the Entry and Exit
Times for the Partitions, as follow.Enter the Identifica-
tion Number of the Zone you want set up.
1. Enter the Identification Number of the Partition you
want set up.
Partition 01
Partition Pt001
2. Press ENTER.
Partition Pt001
Entry time
3. Press a and b to scroll the Entry time and Exit
time, then press ENTER to select the displayed op
-
tion: the display bottom line shows the current value
on the left, and the valid range on the right.
Entry time Pt001
30s : 15/3600
4. Enter the required value.
Ø
You must enter a 4-digit value: e.g. you must press 0,
0, 6 and 0 to enter 60 seconds.
Ø
Press ESC to delete the value.
Ø
Press ESC again to to discharge the changes and go
back to step 3.
Ø
Press ENTER to confirm the value and go back to
step 3.
n
User PINs
Panel Prog.
Users UC---
The User PINs option let you to set up the PIN Parti
-
tions as follow.
1. Enter the Identification Number of the User PIN you
want set up.
User 001
Users UC001
2. Press ENTER.
Users UC001
Part mask
3. Press ENTER again: the characters on the display
bottom line show the Partitions of the selected User
PIN : the 1st is for Partition 1, the 2nd is for Partition
2 and so on, as follow.
Ø
*: the User PIN is assigned to the Partition.
Ø
-: the User PIN is NOT assigned to the Partition.
Part mask UC001
****************
4. Set up the User PIN Partitions as described for the
zones.
Ø In the top example, User PIN 1 is assigned to the
Partitions 1 and 16.
n Keys
Panel Prog.
Keys K---
The Keys option let you to set up the Keys Partitions as
described for the zones.
n
WLS Keys
Panel Prog.
WLS keys WK---
The WLS Keys option let you to set up the Wireless
Keys Partitions as described for the zones.
96 Expandable Hybrid Control Panel
