Connection via Internet (remote IP) To set up con
-
nection via Internet (remote IP), proceed as described
below (see “APPENDIX > Connection via IP” for further
information.
1. Select the Customer Account properties (right click
on the Customer Account’s name, then Properties).
2. Select the type of control panel (for example,
Absoluta 104 v3.5) from Panels/Modules.
3. Type the Installer PIN in the option BOSS Access
Code (default 0104 or 00104 for Grade 3 Control
Panels).
4. Select Absoluta Plugin from the Module menu
then press Add.
5. Select Absoluta Plugin from Panels/Modules >
<Control panel Type> then select IP (Remote) from
the Connection Type menu and press Add.
6. Press Save to leave the factory settings
25
for the re
-
mote IP connection and go to step no. 8, otherwise
read the following step.
7. Select IP (Remote) from Absoluta Plugin then se
-
lect the time that BOSS waits for the connection re-
quest from the IP Module (Connection Timeout),
enter the public IP address for the PC on which
BOSS is installed
26
(BOSS Public IP) and select
the port to access BOSS (BOSS External Port)
then press Save.
8. Select Absoluta Plugin from Panels/Modules >
<Control panel Type> then enter the serial number
of the control Panel and press Save: at this point it
is possible to download/upload options as outlined
in the section “How Downloading/Uploading the
Options”, and manage the Control Panel via the
Status page.
+
On the router connected to the BOSS PC the for
-
warding port from the BOSS External Port (factory
setting 51004) to port 51004 (internal BOSS port,
CANNOT be changed) must be configured: request
router instructions from the network administrator.
Notes for Internet connection (GPRS and IP) To
Download/Upload Options via Internet (GPRS and IP):
Ø
the PC on which BOSS is installed must be con
-
nected to the Internet;
Ø
the PC must have a public IP address and a public
port for incoming connections to the BOSS applica
-
tion;
Ø
the firewall and the router must allow the PC to con
-
nect the public port to port 51004 of the BOSS appli
-
cation;
Ø
the ABS-GSM Module must be installed on the con
-
trol panel (for connection via GPRS) and/or the
ABS-IP Module (for connection via IP) and their op
-
tions must be set as described in the paragraph
“ABS-GSM” and/or “ABS-IP”;
Ø
a SIM card must be inserted in the GSM Module and
the credit on the SIM must be sufficient for GPRS
services.
ABSOLUTA PROGRAMMING FROM THE PC 85
25 The factory settings for remote connection via IP require the Absoluta Server to pass the public IP address for the
PC on which BOSS is installed (option Auto detect ENABLED) and the BOSS External Port 51004 to the IP
Module
26Read the operating system instructions to obtain the public IP address for the PC on which BOSS is installed
