OPERON D 850 SURGICAL TABLE
GENERAL INFORMATION
Rev. 1 700000120
1-2
RADIOLUCENT TABLE TOP AND PADS
CAUTION
CAUTION — The anti-static
properties of the table depend on the
use of the recommended mattress.
Compromise of the anti-static
properties could expose the patient or
OR personnel to an electrostatic shock.
It could also deliver a shock to the
table’s electronics that could damage
or destroy critical components.
The tabletop surface is made from electrically
conductive radiolucent panels. The table is
fitted with a matching set of conductive
radiolucent pads. Velcro tape holds the pads
in place.
CAUTION
CAUTION — Protect the top and
bottom surfaces from nicks and
scratches. Scratches more than 0.005
inches (127 microns) deep may appear
on x-rays. Damaged or scratched
panels should be replaced if x-ray
quality is affected.
Each table section has a cassette channel that can
accommodate x-ray cassettes up to 14'' x 17'' (356
x 432 mm).
INTERCHANGEABLE HEADREST
The headrest can be attached to the seat section to
allow for positioning the patient toward the leg
end of the table.
POWER SUPPLY
WARNING
WARNING — Repeated breaker
tripping or fuse replacement may
indicate a ground fault or overload
condition. The table will not operate
reliably under these conditions, and
may be electrically unsafe. Do not use
the table until these conditions are
corrected.
NOTE
NOTE — Recharge the batteries as
indicated by the battery indicator on
the control pendant. For longevity, it is
good practice to charge the batteries at
least once a week
The locations of the primary Power Supply
components are shown in Figure 1-2.
When the table is plugged into a 120VAC
receptacle, it is powered by AC (mains). When
the power cord is not plugged in, the batteries
provide power to the table. In either case, the
ON/OFF switch on the base must be ON to
articulate any table sections. When the ON/OFF
switch on the base is OFF, the table's electronics
and pump motor are isolated from the power
supply and the batteries, regardless of the pendant
used.
When the charge indicator lamp near the power
cord receptacle is lit, the table senses AC power
and activates the battery charging system. If AC
is present, the battery charging system is activated
whether the ON/OFF switch on the base is in the
ON or OFF position. The table can remain
plugged into AC indefinitely without damaging
the batteries. The battery indicator on the primary
hand pendant displays the battery charge status.
This display has three sections: green (full
charge), yellow (low charge), and red (recharge).
Only one color will be activated at a time.
NOTE
NOTE — In the unlikely event of a
control pendant failure, the table
movements can be stopped by switching
the breaker on the base to the off
(down) position.
