OPERON D 850 SURGICAL TABLE
OPERATING INSTRUCTIONS
700000120 Rev. 1
2-5
User-Controlled Limits
CAUTION
CAUTION — Watch the table at all
times while performing multiple
articulations. Stop table movements
before collisions occur. Failure to
do so could result in damage to the
table.
When accessories are used, some collisions are
possible particularly at low table heights. When
combining functions, you must monitor the
table’s position to ensure collisions are avoided.
HEADREST
WARNING
WARNING — Do not mount knee
crutches or leg holders to the
headrest side rail. The headrest
should only be used for supporting
the head or feet. Do not lean on the
headrest. The headrest has a weight
limit of 50 lbs.
WARNING
WARNING — When articulating the
headrest, be sure that the locking
mechanism engages completely, and
does not hang in between positions.
Until the locking mechanism
engages, the headrest may move
TABLE 2-2 SOFTWARE CONTROLLED LIMITS
Trendelenburg Trend will stop when any table section approaches the floor, base, column,
or when internal components may collide.
Reverse
Trendelenburg
Rev Trend will stop when any table section approaches the floor, base,
column, or when internal components may collide.
Tilt Tilt will stop when any table section approaches the floor, base, column, or
when internal components may collide.
Height
Minimum height – 22.6”
Maximum Table height – 46.4”
Minimum height with Leg down 90° and slide at full foot end – 27.5”
Height Down will stop when any table section approaches the floor, base,
column, etc.
Kidney
Max Kidney height – 3.5”
Kidney up will stop when the back section is greater than or equal to 20°
Back
Max Back up – 90°
Min Back Down – 45°
Back Up will stop at 20° up when Kidney bridge is deployed (regardless of
kidney height)
Leg
Max Leg up – 30°
Min Leg down – 105°
Leg down will stop when the leg section approaches the floor, base, column,
etc.
Slide
Full slide 17”
Trend or Rev Trend angle greater than 10°
Slide disabled
Slide will stop when any table section approaches the floor, base, column,
etc.
Chair, Flex,
Reflex, Urology,
Level
The automatic functions will stop any function that may come in contact with the
floor, base, column, etc.
The Level function may attempt to move another function to remove the crash
situation and complete the leveling of the table top.
