OPERON D 850 SURGICAL TABLE

USING THE SERVICE PROGRAM

700000120 Rev. 1

6-13

3. Hold the Level and On/Off buttons

on the hand pendant simultaneously.

4. Turn the table on at the breaker

switch (base) while holding the

other two buttons on the pendant.

5. When the service light on the

pendant flashes multiple times, the

pendant buttons can be released.

A new level position has been set.

The hydraulic leg cylinders operate in series. In

the event that the leg cylinders were to no longer

be aligned, a software command can be given

through the primary hand pendant to compensate

for uneven leg cylinders. Here is the sequence:

1. Turn the table off at the breaker

switch (base).

2. Hold the leg up and the Level

buttons on the hand pendant

simultaneously.

3. Turn the table on at the breaker

switch (base) while holding the

other two buttons on the pendant.

4. When the service light on the

pendant flashes multiple times, the

pendant buttons can be released.

The leg cylinders automatically

drive upward to their mechanical

limit and re-align.

CPU Error Codes

The CPU is programmed to store error codes for

a series of specific errors. These are numbered

from 1 to 64. 0 shows a listing of these codes

and their causes. The error code table also

includes potential solutions to eliminate many of

the errors.

For errors where no solutions are suggested, you

can use the error name and description to

determine additional diagnostic steps that can be

used to discover the problem and return the table

to service. A Troubleshooting Guide follows the

Error Code listing.

TABLE 6-3 OPERON B850 ERROR CODES

Error Code Type Description Solution

1: MCU 1 : Program memory

checksum error
