OPERON D 850 SURGICAL TABLE
OPERATING INSTRUCTIONS
700000120 Rev. 1
2-3
anesthetizing the patient. If this is required,
the following steps must be followed:
• Be sure that the patient is properly
secured to the table with straps.
• Center (slide) the patient over the main
lift column.
• Lower the table to its lowest point.
• Check the floor for and remove objects
that may interfere with moving the table,
such as power cords or table accessories.
• Have at least one person at each end of
the table.
• Unlock the table.
• When moving the table, the people at
each end must use a lateral force in the
direction of motion; do not lift up on a
section or push down on a section.
• Immediately lock the table when the new
location is reached.
OPERATION
CAUTION
CAUTION — Storage of clamps,
accessories, etc., on the base cover
may result in damage to lift column
shields and prevent proper elevation
or descent of the table.
NOTE
Note — The table can be operated
with or without the power cord
connected to the mains inlet
receptacle. Plug in the power cord if
the batteries need recharging. The
table may be operated while the
batteries are charging.
If desired, plug the table’s power cord into a
mains power source. When the table is plugged
in via the power cord, it is powered by mains
AC. When the power cord is not plugged in, the
batteries provide power to the table. In either
case, the ON/OFF switch on the base must be
ON to articulate any table sections. When the
ON/OFF switch on the base is OFF, the table’s
electronics and pump motor are isolated from
the power supply and the batteries.
When the charge indicator lamp near the power
cord receptacle is lit, the table senses mains AC
and activates the battery charging system.
Battery charging will occur whether the
ON/OFF switch on the base is in the ON or OFF
position. The table can remain plugged into AC
indefinitely without damaging the batteries.
HAND PENDANT OPERATION
The table may be activated by pressing the hand
pendant ON button or by pressing any of the
hand pendant function buttons.
If you activate the table by pressing the ON
button, the hand pendant LEDs for all Battery
levels will flash briefly. This is a self-test
function. During this time, no function is active.
If there is a problem with the hand pendant, the
connection to the table, or any of the table
functions, the SERVICE LED will remain on.
If there are no problems, all LEDs except the
Power, current floor lock status, and battery
status displays will turn off, and the function
buttons will become back lit to indicate that the
table is in a “controls active” status.
To conserve battery power, the hand pendant
will automatically go into SLEEP MODE after a
preset period of non-use (default value). This
time can be changed through the table’s Service
Software Program, which is described in the
“Service Program” section of this manual.
Additionally, hand pendant backlighting will
turn off after a preset period of non-use (default
value). This time can also be changed through
the table’s Service Software Program.
If you activate the hand pendant from the
SLEEP MODE by pressing any of the function
buttons (other than the ON button), the self-test
will be performed after the button is released. If
the floor locks are NOT locked, the back
lighting will come on, and the hand pendant will
go into “controls active” status, the feet will
automatically descend and lock.
1. Press the ON button on the control
pendant to activate the control pendant
2. Press FLOOR LOCK to lower the floor
feet. The green LOCK indicator on the
control pendant will light when the floor
feet are locked.
3. Select the desired function by pressing
and holding the appropriate function
switch.
4. When the desired position has been
reached, release the function button to
stop movement.
5. After the patient has been transferred
from the table, press FLOOR LOCK to
raise the floor lock feet and allow table
transport. The yellow UNLOCK
