The
right
control station is located in the operator's cab next to the
front
con‐
trol station (10).
The machine is switched on and off using the ignition switch (4). The
switches (8) are used for controlling machine functions. The exterior mirrors
are adjusted using the mirror adjustment (7). The cab heater is controlled by
the
Heater/air-conditioning system
(3) control. The operator's cab has an
interior light (6).
The machine is prepared for an optional radio (→ 5.4.12). The radio prepara‐
tion (2) is located at the front right next to the operator's seat.
The diagnostic socket (5) is an interface for customer service.
The operator's cab can be exited via the emergency exit (1) in an emer‐
gency. Here, you can exit in an emergency through the sliding window.
A bottle holder (9) is located below the switch.
Further information about the assignment/function of the switch (→ 8.2).
The number and location of the switches on the
right
control station may
vary depending on the equipment of the machine.
50-020-1011-900_EN
1.0 - © 2/15/2017
125
5 Structure and function
5.2 Technical description of the basic machine (series production equipment)
