8.2.6.6 Dial switch
The particular function is shown on the sign (3) of the dial switch (2). The
setting in question can be read off on the display (1).
The engine speed and maximum speed in working mode are controlled
using the dial switch on the machine.
Increasing the engine speed/maximum speed
►
Turn the corresponding dial switch clockwise.
Reducing the engine speed/maximum speed
►
Turn the corresponding dial switch counterclockwise.
The dial switches are located on the right control station.
Fig. 8.28
50-020-1011-900_EN
1.0 - © 2/15/2017
197
8 Operation
8.2 Operation of the machine
