6.2 Software Functions and System Configuration
52
Measuring Parameter
Detector and Isotope
o Detector code:
Detector-specific code number for automatic high voltage control.
Detector list
Scintillator Type Dimensions
mm
Weight
kg
Detector
code
NaI Plastic
LB 4401-01
LB 5401-01
25/25 6 0
X
LB 4401-02
LB 5401-02
40/35 6 0 X
LB 4401-03
LB 5401-03
50/50 18 0 X
LB 4405-01 500 10 22 (24) X
LB 4405-02 750 10.5 22 (24) X
LB 4405-03 1000 13 13 (15) X
LB 4405-04 1250 13.5 13 (15) X
LB 4405-05 1500 15 10 (12) X
LB 4405-06 2000 22 10 (12) X
Detector code in () can be used to reduce the background. Any
change in the detector code requires a new calibration.
o Isotope Select:
Select the isotope used for the measuring configuration so that the
nuclide-specific factor for the automatic half-life correction be-
comes effective for automatic decay compensation. You can select
either Am/Co/Cs/Kr/Cm.
