7.1 MAIN DECK - EXTERIOR
1. Transom fish box
2. Aft moorings, chocks and cleats
3. Removable containers for caught fish and
access to helm gear compartment
4. Rods holder, boat hook and gaff storage
under gunnel
5. Mounting plate for fighting chair or table
6. User peaks
• shore electric power outlets
• dockside water inlets
• firefighting system controls
• cockpit washdown faucets
•switches
7. Fish boxes
8. Engineroom access door, with lockable
access stair
9. Fuel fill fittings
10. WASTE black water drain fitting
11. Staterooms skylights
12. Anchor locker with washdown faucet
• Anchor winch
13. Salon access door
14. Salon access steps
15. Baitwell
16. Flybridge access stair
17. Aft transom door and liftable gate
