ON DECK
Studio ti 03312 540-04usa
121
7.4 ANCHOR WINDLASS
(available only with optional pulpit)
The on board anchor windlass allows to face each anchoring condition,
even the most critical one with a certain margin of safety.
The anchor windlass is used to weigh and lower the anchor. It may also
be used as warping windlass for pulling a line.
The chain to which the anchor is linked, glides inside of the yacht through
the chain guide and reaches the anchor windlass, it then turns around the
wildcat and glides into the chain pit. Each anchor windlass is equipped
with a control to handle the chain in both directions and with manual
brake to lock the chain position during the moorings.
1. Lever connecting bushing
It allows the lever connection.
2. Capstan
It allows to pull a line.
3. Wildcat
It allows to retrieve and to deploy the anchor.
4. Safety hook
It allows to lock the anchor chain.
