ON DECK
Studio ti 03312 540-04usa
123
7.4.1 Anchor windlass activation controls
The anchor windlass is located at bow and can either be activated by the
switch located on the helm station console or by the foot buttons.
1. Anchor windlass control on flybridge
This button allows to operate the anchor windlass from the fly.
2. Foot button “UP”
This button allows to retrieve the anchor chain.
3. Foot button “DOWN”
This button allows to deploy the anchor chain.
S
CAUTION
If you are to use the anchor, remove the wildcat lock and the safety
cable.
S
CAUTION
Do not approach your body or objects to gliding chains, to lines or
wildcats. Make sure that the electric motor is not supplied when the
anchor windlass is operated manually (even when the lever to release
the clutch is moved), as persons in possession of the anchor windlass
remote control may accidentally activate it.
Helm station windlass Foot buttons
