10.4 24 V DC USER FLYBRIDGE ELECTRIC PANEL
On the flybridge is installed an electric panel equipped with circuit breakers
protecting the 24 V DC users and the measuring instruments of the system.
The following main sections have been identified, in order to make the
descriptions easier:
A. Voltmeter and ammeter for 24 V DC batteries
B. Circuit breakers protecting the 24 V DC users
S
CAUTION
High voltage
Disconnect the electric power supply before opening the door.
S
CAUTION
Switch off the generator, the inverter and disconnect the shore outlets
before opening the panel.
NOTICES
The description of the electric panel is referred to the standard version
of the yacht.
