PROPULSION SYSTEMS
Studio ti 03312 540-04usa
156
8
1. Level gauge in the engineroom
2. Main fuel delivery valve
3. Port engine fuel delivery valve
4. Starboard engine fuel delivery valve
5. Generator fuel delivery valve
6. Fuel level delivery valve
7. “RACOR” separator filter for generators
8. “RACOR” separator pre-filters for starboard engine
9. “RACOR” separator pre-filters for port engine
10. Helm station level gauge
11. Full tank buzzer
i
ENVIRONMENT
Every marina has toxic waste disposal dedicated areas. It is
recommended to dispose polluting waste (such as used oil, fuel, oily
liquids, batteries, etc.) according to the environment protecting laws.
Prior to performing any job in the engineroom, disconnect the bilge
pumps switches, in order to prevent that accidental fuel, lubricant or
other liquid leakages pollute the surrounding waters.
b
DANGER
Due to high temperature in engineroom, oil or fuel leaks can evaporate
and create a serious risk of fire break.
b
DANGER
Fuel leak can be the cause of fire. Periodically check the integrity of
Your installation.
