ELECTRIC SYSTEM
Studio ti 03312 540-04usa
245
The yacht is equipped with two isolation transformers located in the
generator room, capable of galvanically isolating the yacht’s electrical
system from the shore electrical system.
To use the electric power supply from dock:
−
Turn OFF the AC shore master power supply breakers on the main
electric panel of the salon.
−
Set to OFF the switch of the dock column.
−
Plug-in the electric cable winder in the dock socket.
−
Turn ON the circuit breaker on the shore column.
−
Turn on the general circuit breaker of the relative shore power outlet
used and all the breakers located on the main electric panel.
To service the electric power supply from shore:
−
In a marine environment, all exposed metallic segments of cables and
ducts, must be cleaned periodically with fresh water, while the shore
power supply is not in use. Dry and spray with moisture repellent.
−
Periodically apply vinyl protector to the cables’ plug.
S
CAUTION
Do not modify connectors of dock power supply cable, use only plug
compatible connectors. If the yacht power supply cable cannot be
plugged into the dock socket, ask the Port Authority for an adapter.
S
CAUTION
Do not place your hands into the hawse pipe when retrieving the cable.
j
WARNING
To prevent the cable from becoming tangled in moving machinery,
always check to be certain that all of the cable is contained in the drum
when completely retrieved.
S
CAUTION
To interrupt shore electric power supply:
−
turn OFF the main circuit breaker of the shore power outlet used;
−
turn OFF the protection on the shore column;
−
disconnect the dock supply cable and rewind it by means of the cable
winder;
−
securely fasten the lid of shore power supply outlet.
S
CAUTION
Disconnect the dock power supply connections when the system is not
in use.
j
WARNING
Do not allow that cable end of dock power supply to floats in the water.
This can cause an electric field and following injuries or even the death
of the swimmers nearby.
