AUXILIARY EQUIPMENT ON BOARD
Studio ti 03312 540-04usa
73
The system operates in three modes for cruising: MANUAL, POWER
STEERING and AUTOPILOT. Switching from one mode to another is a
simple operation.
Manual control of steering always overrides the autopilot.
This is a safety feature and it simplifies steering control. Taking manual
control when the autopilot is on will not damage the system. Turning the
wheel to avoid an unexpected obstacle is a natural reaction. When the
steering wheel is released from manual control, the autopilot will return to
the heading it was steering without any additional intervention.
NOTICES
At high speed, the use of the autopilot is dangerous and not
recommended. Anyway, be always very careful during navigation also
when the autopilot is in use.
S
CAUTION
CONTROL HAZARD
Inspect and service the driving system regularly. An improperly serviced
driving system may get damaged, causing the sudden loss of control,
resulting in personal injury and property damage.
−
Follow instructions in owner’s information packet for hydraulic driving
system operation, for filling and bleeding procedures, for alternative
means of operation, for service procedures, troubleshooting, fluid
specifications, systems plans and replacement parts list.
−
Follow instructions in owner’s information packet for mechanic driving
system inspection and lubrication.
−
In a hydraulic system, the drive wheel movement pump hydraulic fluid
into the lines until they reach a cylinder which transfers the movement
to the rudder, aft drive; a tank holds the exceeding fluid; a valve
protects against overexposure.
−
The operator must inspect the driving system frequently for a smooth,
free and full range operation.
