Binder CB 160 - Page 130

CB (E6.1) 07/2017 Page 130/145
Chamber size
60
160
220
CO
2
data
CO
2
range
vol.-% CO
2
0 to 20
0 to 20
0 to 20
Setting accuracy
vol.-% CO
2
0.1
0.1
0.1
Recovery time after door was opened for
30 sec at 5 vol.-% CO
2
minutes 5 5 5
CO
2
measurement
IR
IR
IR
Connection hose nozzle DN6 for CO
2
connection to the chamber for hose with
internal diameter
mm / inch 6 / 0.24 6 / 0.24 6 / 0.24
Humidity data
Humidity
% r.H.
90 to 95
90 to 95
90 to 95
O
2
Data
O
2
range (regular equipment)
vol.-% O
2
0.2 to 20
0.2 to 20
0.2 to 20
O
2
range (chamber with optional alternative
control range 10 up to 95 vol.-% O
2
vol.-% O
2
10 to 95 10 to 95 10 to 95
Setting accuracy with inlet pressure 2 bar
vol.-% O
2
0.1
0.1
0.1
Recovery time after door was opened for
30 sec at 1 vol-% O
2
minutes 8 12 18
Recovery time after door was opened for
30 sec at 5 vol-% O
2
minutes 8 12 18
O
2
measurement
ZrO
2
ZrO
2
ZrO
2
Connection hose nozzle DN6 for O
2
/N
2
connection to the chamber for hose with
internal diameter
mm / inch 6 / 0.24 6 / 0.24 6 / 0.24
Electrical data
IP system of protection acc. to EN 60529
IP
20
20
20
Nominal voltage
(±10 %)
at 50 Hz power frequency
V
200-240
200-240
200-240
at 60 Hz power frequency
V
200-240
200-240
200-240
Current type
1N~
1N~
1N~
Nominal power
kW
1.00
1.30
1.50
Power plug (IEC connector plug)
Shock-proof plug
Installation category acc. to IEC 61010-1
II
II
II
Pollution degree acc. to IEC 61010-1
2
2
2
Chamber fuse 4x20mm / semi time-lag (M)
Amp
10
10
10
Different electrical data for CB-UL constructed for the USA and Canada
Nominal voltage
(±10 %)
at 50 Hz power frequency
V
100-120
100-120
100-120
at 60 Hz power frequency
V
100-120
100-120
100-120
Current type
1N~
1N~
1N~
Power plug
NEMA
5-15P
5-20P
5-20P
Nominal power
kW
1.00
1.30
1.50
Chamber fuse 6.3 X 32 mm / 250V / super-
time-lag TT
Amp 16 external 16 external 16 external
Additional temperature fuse class 1 (DIN 12880)
internal
internal
internal
Environment-specific data
Energy consumption at 37 °C/ 98.6 °F
Wh/h
80
100
120
Note: The recovery times of the gas concentrations inside the chamber after the door is opened coincide
with a connection pressure of 2.0 bar / 29 psi. Decreasing supply pressure results in longer recovery
times.
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of 22 +/- 3 °C / 71.6 +/- 5.4 °F and a power supply voltage fluctuation of +/-10%. Technical data is
determined in accordance to BINDER Factory Standard Part 2:2015 and DIN 12880:2007.
