CB (E6.1) 07/2017 Page 17/145
Temperature range: 7 °C / 12.6 °F above ambient temperature up to +60 °C / 140 °F
CO
2
range: 0 vol.-% up to 20 vol.-%)
O
2
range (chamber with O
2
control): 0.2 vol.-% up to 20 vol.-% (hypoxic control range) or 10 Vol.-%
up to 95 Vol.-% (alternative control range)
2.1 Chamber overview
Instrument panel with microprocessor
controller T4.12 and USB interface
Door handle
Chamber door
Main power switch
Figure 3: CO
2
incubator CB (example: model CB 160)
2.2 Instrument panel
5,7" controller display
Context-sensitive buttons
USB interface
Operating button
Pilot lamp: ready for operation
Figure 4: Instrument panel with microprocessor controller T4.12 and USB interface
