6.1 Menu structure
Fixed value
08.03.2013 05:05:06
Initial view (sample values, chamber with O
2
control).
Press the desired menu button.
Setpoint
Actual value
Temperature [°C]
37.0
37.2
CO2 [Vol.-%]
5.0
5.0
O2 [Vol.-%]
20.7
20.7
User Quick menu
Menu
From the Initial view you have access to different menus using the menu buttons “User”, “Quick menu”, or
“Menu”. From there you can access the desired control functions. To do this, select the function by
turning the operating button and press the operating button to confirm the selection.
In any menu, you can return to the previous display pressing the "Close" button or to the initial view with
the "Home" button.
Depending on the logged-in user or administrator, the available menu functions may vary. These
instructions present the functions which are available to the logged-in administrator.
6.1.1 General menu
The general menu provides access to all setting functions of the controller, a graphical display of the
measured values, and the possibility to read and give out data via the USB interface. In addition,
supporting functions like a settings wizard or a contact page are available.
Fixed value
08.03.2013 05:05:06
General menu
..\ Menu
Controller mode
Event list
Alarms
Setpoints
Safety controller
Import/Export
Hot-air sterilization
Humidity control
Close Home
Turn the operating button to see additional menu items.
